ASUS ROG Rapture GT AC5300 Review

Overview of the ASUS ROG Rapture GT-AC5300 Tri-Band Wireless Router
If a device receives a “gaming” prefix, it automatically means that its capabilities are focused to the needs of gamers. But what are the first associations that come at the mention of the gaming router? The presence of a fast channel at 5 GHz? This can boast of ordinary models. Prioritizing gaming network traffic? Also far from exclusive feature.
gt ac5300 review

In this review we will try to figure out why the ASUS ROG Rapture GT-AC5300 is called a game router and what advantages it will bring to you. What makes it stand out from ordinary routers and how good it is in test metering. And all this, so that you make a conscious choice for yourself - is it worth it to buy it or can you get by with a simpler device.

ASUS ROG Rapture GT-AC5300
Type of
Tri Band Wireless Router
Device class
Wireless standards
802.11a / b / g / n / ac
Supported frequency ranges
2.4 GHz + 5 GHz + 5 GHz
Maximum throughput
5334 Mbps (1000 + 2167 + 2167)
8 x external antennas
Transmit / Receive
4 x 4 (2.4 GHz)
4 x 4 (5 GHz)
4 x 4 (5 GHz)
Permanent memory
External interfaces
1 x RJ45 (WAN, 10/100/1000 Mbit / s)
8 x RJ45 (LAN, 10/100/1000 Mbit / s)
2 x USB 3.0
WAN connection
Automatic IP Address, Static IP Address, PPPoE (MPPE), PPTP, L2TP
Guest network
3 x 2.4 GHz
3 x 5 GHz
3 x 5 GHz
Wireless security
64-bit WEP, 128-bit WEP, WPA2-PSK, WPA-PSK, WPA-Enterprise, WPA2-Enterprise, Radius with 802.1x, WPS
Supported Protocols
IPv4, IPv6
Modes of operation
Wireless router, access point, repeater, Media Bridge
Additional benefits
Link Aggregation, MU-MIMO, Airtime Fairness, Smart Connect, Traffic Analyzer, Adaptive QoS, AiProtection, Parental Control, VPN server, VPN client, Mac OS Backup, Enhanced media server, AiCloud 3G / 4G, Printer Server, Download Master, AiDisk, Dual WAN, IPTV, Roaming Assist
Power Supply
65 W (19 V at 3.42 A)
245 x 245 x 65 mm
Package Included:
  • a set of paper documentation;
  • Ethernet cable;
  • eight removable antennas;
  • power supply ADP-65DW C with a capacity of 65 W (19 V at 3.42 A).
gt-ac5300 router

Appearance and hardware platform
At first glance, it becomes clear that we face a top-class gaming device. This is indicated by the aggressive asymmetrical design, the characteristic pattern of the top cover and the logo of the ROG line on it. ASUS ROG Rapture GT-AC5300 will definitely attract the attention and envy of your friends and acquaintances.
gaming router

gt ac5300 body is made of matte plastic, but the prints on it are still noticeable. It’s good that they can be easily removed with a regular rag. On one of the sides are all six available indicators. They are lit in white and do not attract excessive attention. With their help, you can immediately determine whether the router is on, which wireless range is used, whether there is an Internet connection, whether a wired connection is being used and the current state of WPS.

On the other side there are three useful buttons. The first turns on / off the LED indicators. The second activates WPS technology for quick pairing with compatible devices. The third one turns on / off wireless broadcasting.
best gaming router settings

All interface connectors are conveniently assembled on one side. Nice to see two USB 3.0 ports and eight RJ45 wired clients. Moreover, LAN1 and LAN2 (the uppermost ones on the left) are special gaming ports. The game traffic passing through them automatically receives the highest priority. Therefore, it is better to connect a computer, laptop or gaming console to them. And for NAS systems there are LAN5 and LAN6 ports (the lowermost ones on the left). They support Link Aggregation technology to combine the two interfaces into a single channel with a bandwidth of 2 Gb / s (the client device must support the 802.3ad standard).

The last sidewall carries the remaining two of the eight connectors for connecting external antennas. In the lower part of it are traditionally vents.

asus gt-ac5300 firmware
The lower part meets us with a set of traditional elements. Along the edges there are large rubber legs that are needed to conveniently and securely hold the router on the table. They raise the body, improving heat transfer, and prevent the appearance of scratches on the table.

The main part of the bottom cover is covered with ventilation slots. And in the center is a sticker with important technical information. Here are the power settings, the web address for the initial configuration, the standard names of each frequency range (SSID), MAC address, PIN code and other useful information.

According to information from the official website , the ASUS ROG Rapture GT-AC5300 is based on a 4-core Broadcom BCM4908 processor with an operating frequency of 1.8 GHz. He is also responsible for the work of eight Gigabit Ethernet interfaces. He is assisted by 1 GB of RAM and 256 MB permanent. The implementation of all wireless protocols is assigned to three Broadcom BCM4366E chips - each is responsible for its own frequency range (one for 2.4 GHz and two for 5 GHz).

Now let's talk a little about the functionality of the ASUS ROG Rapture GT-AC5300 router. It supports the 802.11ac Wave 2 standard, which offers a number of useful benefits:
  • Increase channel width up to 80 MHz.
  • MU-MIMO technology support for simultaneous service of several clients.
  • AirTime Fairness technology support. It provides the same access time for devices to the radio, regardless of their internal speed. Previously, the principle of equality of opportunity was tied to the number of packets received, so if a fast and slow device was connected to the network, then the fast one had to wait until the slow one received all its packets. And the principle AirTime Fairness solves this problem, not allowing slower customers to reduce system performance.
  • Beamforming technology support. It focuses the wireless signal in the direction of the client to create a more reliable and high-quality communication channel.
GT AC5300 Review

Used Broadcom BCM4366E chips support 1024-QAM modulation. That is, it increases the bandwidth of the 2.4 GHz channel from 600 to 1000 Mbit / s, and for the two 5 GHz bands from 1734 to 2167 MHz.
ASUS ROG Rapture Review
ASUS ROG Rapture GT-AC5300 boasts a three-level system of accelerating gaming traffic. The first level is the two mentioned LAN ports with the function of prioritizing gaming traffic. The second is Game Boost technology. It works in conjunction with the same ports to maximize the speed of gaming network traffic. The third level is the built-in support of the Gamers Private Network system from the WTFast company. It automatically optimizes the route for sending data packets, which allows reducing delays (Ping) by 30-60% and packet loss by 70-90%.
asus gt-ac5300 firmware

To manage all the features of the router provides a convenient program Gaming Center. It provides access to the Game Dashboard control panel (gives information about all active network connections), the mentioned Game Boost technology and the Gamers Private Network system, the IPS protection system and VPN Fusion technology, and also shows the location of the fastest game servers on the ping card. The program is available for PC and mobile devices.

If you use a VPN, you probably noticed a drop in bandwidth and a decrease in the speed of downloading content when this feature is activated. This is extremely unpleasant in games. Therefore, you will surely enjoy VPN Fusion technology. It allows you to use a regular Internet connection in parallel with a VPN, without losing speed.
asus rog ac5300 review
Protection of the entire gaming network is provided by the Intrusion Prevention System (IPS). It is based on Trend Micro technology. IPS allows you to disable the antivirus installed on your PC and the firewall for the duration of the gaming session in order to free up system resources and avoid accidentally blocking game data with a too strict protection system.

At the same time, IPS takes complete protection of the system against online attacks, blocks access to malicious sites, detects already infected devices and blocks their work so that they cannot send your personal data to hackers.
Another useful technology is RangeBoost. This is a set of hardware and software for expanding the range of a Wi-Fi network.
Also, ASUS ROG Rapture GT-AC5300 is ideal for creating a wireless network in a big house, because it supports AiMesh technology. This allows you to combine several compatible routers into a single system with automatic connection to the node with the strongest signal.
July 1, 2019
